SINAN NETWORKS
포스(POS)
E-250
브랜드 가치를 높여주는 스마트한 디자인
-
ㆍ 부드러운 안정감과 여유공간
-
ㆍ 고성능 스피커 지원
-
ㆍ 감각적인 컬러 배색, 투톤
-
ㆍ 심플한 구조
-
ㆍ 강력한 고성능 프로세서 탑재
-
ㆍ 200series의 안정성과 특장점을 100% 적용
-
ㆍ 유리(Glass) 터치 패널
-
ㆍ 제품 안정성 강화 슈퍼 방열 프레임 설계
| System | Processor | Intel® Celeron® Quad-core Processor J6412 2.0GHz/2.6GHz |
|---|---|---|
| Chipset / BIOS | Intel® Elkhart Lake SoC / AMI | |
| Storage | 2.5" SATA III SSD 128GB (HDD 500GB) | |
| Memory | 4GB SO-DIMM, DDR4 2666MHz~3200MHz x 1 (Max 32GB, optional) | |
| Graphics | Intel® UHD Graphics for 10th Gen Intel® Processors | |
| Multi Monitor | 3 (# of Displays Supported) - up to 3 monitors (optional) | |
| OS | Windows 10 IoT Enterprise(64bit), Windows 11(64bit) | |
| Display | Primary Display Type | 15" WLED Backlight (Brightness: 350 cd/㎡, 1024 x 768 Resolution) |
| Touch | True-Flat Capacitive 10 Point Multi-touch | |
| I/O Interfaces | USB | 2 x USB 2.0 (Rear Top x 2), 4 x USB 3.0(Rear Bottom x 4) |
| Serial | · 6 (DB9 x 3, RJ50 x 2, RJ11 x 1) COM1, 3, 5: DB9(+5V on pin #9, selectable by
BIOS) · COM2, 4 (RJ50, RJ45): Support +5V and 12V(G200 only) for Special Devices and can be used for Kitchen Printer · COM6(RJ11): USB 2.0 and RS232 with +5V/1A for Card Reader |
|
| Audio | 1 x Audio-out / 3.5mm | |
| Secondary Display | 1 x DisplayPort (included 1 x USB 2.0 / Power Delivery +12V) *Can be used for HDMI and Standard DVI, VGA monitor by passive cable. | |
| LAN | 1 x RJ45 (Base-T 10/100/1000 Ethernet) | |
| Speaker (optional) | 3W x 1 | |
| Peripheral Options | Secondary Display | • LCD Type: 9.7" or 15" LCD (USB Port x 1) • Touch Monitor: 9.7" or 15" LCD with Capacitive Touch (USB Port x 1) - by single cable(no power & USB cable) • Standard Monitor: supported standard DP, HDMI, DVI, VGA monitor by change monitor cable • Standard and Powered DP MST Hub: supported standard or powered(customized) DP MST Hub. |
| Customer Display (CDP) | FSTN LCD Type (20 columns x 2 lines) | |
| Card Reader (MSR / SCR) | Smart Card Reader: ISO/IEC7816 EMV Level 1 / Magnetic Stripe Reader: ISO 7811 ID-1 All tracks *Interface: USB(HID) and RS232C(COM6) | |
| Physical Dimension | Dimension (W x D x H) | 362 x 237 x 357 (mm) / 14.2 x 9.3 x 14.0 (inch) |
| Weight | 4.5 (Kg) / 9.9 (lb) | |
| Box Dimension | Dimension (W x D x H) | 430 x 290 x 430 (mm) |
| Weight | 6.7 kg | |
| Environment | Power Supply | DC 12V/5A (AC 100V~240V, 60W) |
| Temperature | Operating: 0 ~ 50℃ at 10% to 90% humidity | |
| Certifications | CE, FCC, KC, CB |
